Technical configuration and performance advantages of 3-ton Trackless Material Flat-Trailers for Factory Heavy Load Material Handling
1. Frame main girder is made of rectangular steel tube (two main girders), side girder is made of 8# channel steel (material mechanical properties are not lower than Q235A), mesa is made of frame box structure, and bottom plate is made of 4mm hot-rolled pattern steel plate (Q235B). No deformation occurs under full load and normal loading, unloading and impact, increasing bearing capacity and improving 3-ton Trackless Material Flat-Trailers for Factory Heavy Load Material Handling stability.
2. In order to meet the operation requirements, the bottom of the flat plate (left and right sides) are equipped with four tie-up points, and the material of the tie-up is 12 round steel.
3. 3-ton Trackless Material Flat-Trailers for Factory Heavy Load Material Handling front wheel steering (two wheels), rear axle load bearing (two wheels), Trailer no shock absorption system, four solid tires 500-8.
4. The traction handle is adjustable and disassembled. The traction hook can be adjusted from 250 mm to 600 mm. The traction frame is welded with a length of 1.5m (from the front of the trailer to the center of the traction ring). The traction handle does not land when parking.
5. The steering mechanism is a large-planar fully enclosed single-volleyball rotary disc, which has large bearing capacity, flexible and reliable steering, and can realize 360 degree free rotation of steering angle.
6. The main axles of steering bridge and load-bearing bridge are made of 45 # steel. After quenching and tempering treatment, the overall strength is good and the bearing capacity is strong.
7. The 3-ton Trackless Material Flat-Trailers for Factory Heavy Load Material Handling body primer is iron red epoxy resin, and the topcoat color is engineering yellow.
