Customised orbital electric flatcars - Customised electric flatcars for 360 degree rotating platforms
Xi'an electric flat car users develop a rail electric flat car that can rotate the platform 360 degrees, is the technical research and design department of Xinxiang PERFECT.
The workpiece can be rotated at will when the flat carriage cannot be moved. It is particularly suitable for paint and sand blasting rooms. The main structure of this series of electric flat carriages is divided into two layers, one with powered components. Depending on the workpiece processed and the placement position in the user's production process, a variety of power supply methods can be used, and 360 degree rotating supports and rotating supports can be installed for the design of the centre or eccentric part of the platform's rotation requirements. Also, it can be set up as a manual control method and an electric control method to facilitate production and can be connected to a second level platform to achieve rotational goals.
1. Loading of 30 tons.
2. Platform size: 3200mm*2500mm.
Three, power supply mode: rail type power supply.
4. operation mode of wireless remote control.
5. Motor power: 2.2kw.
6. 0-30m/min running speed.
7. wheel diameter: 400mm.
8.Special requirements: additional lifting function for flat carriage, lifting height 300mm.
9.Using wireless remote control, remote operation can be realized. Electric flatcars have been invested in a large number of turning technologies in different industries.
In recent years, effective measures have been taken to increase the new round of global competition for talent. Competitive advantage. At the same time, the global competition for innovative manufacturing talent is fierce, as many restrictions have been taken on the transfer of technology, industry, links and core talent.
